Advantages.. 1.Quick quarter turn on-off operation 2.Minimal resistance to flow 3.Smaller in size than most other valves
Main parameter of the Plug valve |
|
ANSI Plug valve
|
Class 150LB-2500LB SIZE 1/2"~14" |
DIN Plug valve
|
DN50-DN350, PN16~PN40 |
JIS Plug valve
|
DN50-DN350 10K~63K |
BS Plug valve
|
DN50 -DN350, PN16~PN40 |
Material
|
WCB,LCB,WC6,WC9,C12,C5,CF8,CF3,CF3M,CF8M,A105,LF2,F11,F22,F5,F304,F316,F304L,F316L(2"~14") A105,LF2,F11,F22,F5,F304,F316,F304L,F316L(1/2"-2" ) |
Design & Manufacture Std
|
API600, API 6D,ASME B16.34, JISB2071, JISB2073,JISB2083, BS 1873,BS1414 |
Face to Face Std
|
ASME B16.10,DIN 3202,BS2080, API 6D, JISB2002 |
End Connection Std
|
ASME B16.11,ASME B1.20.1,ASME B16.5, DIN2543-2550 ,JISB2212-JISB2214 |
Test Standard
|
ISO5208,BS 6755, API598,API 6D,JISB2003,DIN3230 |
